Loading Envelopes

This section describes how to load envelopes in the MP tray.

  1. Open the MP tray.

  2. Pull the paper support out.

  3. Open the sub support.

  4. Adjust the manual feeding paper guide to the width of an envelope to be loaded.

  5. Load an envelope with the print side up until its edge touches the paper feed entrance.

    Note

    Do not load envelopes above the "" mark.

    Memo

    Load envelopes with the address side up in the direction as described below.

    If you are using envelopes with the flap (for gluing) on the long edge (Monarch, Com-9, Com-10, DL, C5, C6), load them with the flap folded so that the flap is on the left side when fed.
